Superbright RGB LEDs

Rainbow/Multicolor/Tri-color
LED Pricelist How to Order

RGB LED
X-Type PLCC4 3.5 x 2.8mm 4pins
Order No.	Chip		Wave lenght (nm)	Electro–optical characteristics			2Ø1/2 Half intensity angle (°)
	Raw mater.	Emited color		Vf(V)		lv@20mA (mcd)
	Raw mater.	Emited color		Typ.	Max.	lv@20mA (mcd)
PLCC4XRGBCT	GaAlInP	Super Red	620~630	1.8	2.5	200mcd	120°
	GaInN	Pure Green	520~530	2.8	3.5	560mcd
	GaInN	Blue	465~475	2.8	3.5	110mcd
X-Type PLCC6 5.5 x 5.0mm 6pins
PLCC6XRGBCT	GaAlInP	Super Red	618~628	1.8	2.3	600~900mcd	120°
	GaInN	Pure Green	520~530	2.9	3.5	1200~1585mcd
	GaInN	Blue	465~475	2.9	3.5	240~320mcd
PLCC4 2.1 x 2.1mm 4pins
PLCC4RGB-2121	GaAlInP	Super Red	620~630	1.8	2.5	115mcd	105°
	GaInN	Pure Green	520~530	2.8	3.5	290mcd
	GaInN	Blue	465~475	2.8	3.5	40mcd
Total flux of this LED is up to 8200 mlm / brightness 1600mcd. This high reliability LED has been developed i.e. for gaming machines.
			PLCC4 4pins common anode
PLCC4RGBCT-CA (common anode) Datasheet	GaAlInP	Super Red	620~ 630	2.0	2.4	102~280mcd	110~130°
	GaInN	Pure Green	520~ 530	3.2	3.5	280~770mcd
	GaInN	Blue	465~ 475	3.2	3.6	145~280mcd
Total flux of this LED is up to 5000 mlm / brightness 1000mcd.
			PLCC6 50x50 6 pins, no common - every color has own CA/CC set
PLCC6RGBCT Datasheet	GaAlInP	Super Red	620~ 630	2.1	2.5	390-700mcd	110~130°
	GaInN	Pure Green	520~ 530	2.9	3.4	770-1400mcd
	GaInN	Blue	465~ 475	3.0	3.4	200-300mcd
Total flux of this LED is up to 5000 mlm / brightness 1000mcd.
			5MM Fast/Slow Change RGB LED
5XRGB-F2-F Datasheet	AlGaInP	Super Red	620~ 640	2.0	2.25	800~1500mcd	30°
	InGan	Pure Green	515~ 530	3.3	4.0	2000~4000mcd
	InGan	Blue	460~ 475	3.3	4.0	1000~2000mcd
Total brightness of this LED is up to 7500 mcd lv=60mA (20mA for each chip).
5XRGB-F2-S Datasheet	AlGaInP	Super Red	625~ 640	2.0	2.25	2000~4000mcd	30°
	InGan	Pure Green	520~ 530	3.3	4.0	6000~9000mcd
	InGan	Blue	460~ 475	3.3	4.0	2000~4000mcd
Total brightness of this LED is up to 17000 mcd lv=60mA (20mA for each chip).
			5MM RGB Water clear lenses
Common Cathode Types
540R2GBC-CC (common cathode) Datasheet	GaAlInP	Super Red	625	2.0	2.5	1500~2100	35~40°
	GaInN	Pure Green	525	3.5	4.0	4200~5800
	GaInN	Royal Blue	460	3.5	4.0	1100~1500
Total brightness of this LED is up to 9400 mcd lv=60mA (20mA for each chip).
599R2GBC-CC (common cathode) Datasheet	GaAlInP	Super Red	625	2.0	2.5	310~435	85~100°
	GaInN	Pure Green	525	3.5	4.0	770~1080
	GaInN	Royal Blue	460	3.5	4.0	200~390
Total brightness of this LED is up to 1900 mcd lv=60mA (20mA for each chip).
Common Anode Types
540R2GBC-CA (common anode) Datasheet	GaAlInP	Super Red	625	2.0	2.5	1500~2100	35~40°
	GaInN	Pure Green	525	3.5	4.0	4200~5800
	GaInN	Royal Blue	460	3.5	4.0	1100~1500
Total brightness of this LED is up to 9400 mcd lv=60mA (20mA for each chip).
599R2GBC-CA (common anode) Datasheet	GaAlInP	Super Red	625	2.0	2.5	310~435	85~100°
	GaInN	Pure Green	525	3.5	4.0	770~1080
	GaInN	Royal Blue	460	3.5	4.0	200~390
Total brightness of this LED is up to 1900 mcd lv=60mA (20mA for each chip).
5MM RGB LEDs has four pins in following order: 1: Green - 2: Common (Anode or Cathode) - 3: Blue - 4: Red We can do any pin sequence, but for another pin sequence min. order 10K
