How to buy

Minimum order US$25 mixed OK
Minimum order for countries where we have established a distributor is $199

All our Products are RoHs compliant !

For how to order, delivery time, guarantees etc. read our "how to's".

About us

Our group is Chinese Manufacturer which owns 3 factories and 4 workshops:
Export items:
1. LED diodes
2. Cooling modules
3. Heatsinks
4. LCD modules
Domestic market:
5. Multimeters
6. Connectors + cables
7. Switches
Factories are located in Jiangsu and Zhejiang provinces in China.

New Arrival

COB LEDs 3W~120W

Pricelist   How to Order
Order No. Dimension
in mm		 CT Vf(V) mA LM Watt CRI Watt Range Picture
SG0N3W6-50mA 9.5x9.5x1 White 6000K 62 50 300 3 >70 ≤4.5W
SG0N3W3-50mA Warm White
3000K		 240 >80
SG0N4.5W6-500mA White 6000K 9.3 500 450 4.5 >70 ≤6.5W
SG0N4.5W3-500mA Warm White
3000K		 360 >80
RG3N5W6-500mA Φ30x1 White 6000K 9.3 500 550 5 >70 ≤7.5W
RG3N5W3-500mA Warm White
3000K		 440 >80
RG3N5W6-350mA White 6000K 15.5 350 600 5 >70 ≤7.5W
RG3N5W3-350mA Warm White
3000K		 480 >80
RG3N7W6-750mA White 6000K 9.3 750 830 7 >70 ≤10W
RG3N7W3-750mA Warm White
3000K		 650 >80
RG3N20W6-700mA White 6000K 31 700 2600 20 >70 ≤30W
RG3N20W3-700mA Warm White
3000K		 2080 >80
RG3N25W6-700mA White 6000K 37.2 700 3100 25 >70 ≤35W
RG3N25W3-700mA Warm White
3000K		 2480 >80
RG3N40W6-1400mA White 6000K 31 1400 5000 40 >70 ≤50W
RG3N40W3-1400mA Warm White
3000K		 4000 >80
SG4N4.5W6-30mA 22x17x1 White 6000K 150 30 460 4.5 >70 ≤6.75W
SG4N4.5W3-30mA Warm White
3000K		 370 >80
SG4N6W6-30mA White 6000K 200 30 650 6 >70 ≤9W
SG4N6W3-30mA Warm White
3000K		 520 >80
SG4N10W6-350mA White 6000K 28 350 1150 10 >70 ≤15W
SG4N10W3-350mA Warm White
3000K		 920 >80
SG4N13W6-700mA White 6000K 18.6 700 1550 13 >70 ≤19.5W
SG4N13W3-700mA Warm White
3000K		 1240 >80
SG4N15W6-700mA White 6000K 24.8 700 2050 15 >70 ≤22W
SG4N15W3-700mA Warm White
3000K		 1640 >80
SG4N18W6-700mA White 6000K 27.9 700 2300 18 >70 ≤25W
SG4N18W3-700mA Warm White
3000K		 1840 >80
SG7N40W6-1400mA 28x28x1 White 6000K 30 1400 5400 40 >70 ≤75W
SG7N40W3-1400mA Warm White
3000K		 4300 >80
SG7N50W6-1500mA White 6000K 31 1500 5500 50 >70
SG7N50W3-1500mA Warm White
3000K		 4400 >80
SG7N60W6-1800mA White 6000K 33 1800 6200 60 >70
SG7N60W3-1800mA Warm White
3000K		 4960 >80
SG9N80W6-1500mA 38x38x1 White 6000K 54 1500 10500 80 >70 ≤150W
SG9N80W3-1500mA Warm White
3000K		 8400 >80
SG9N100W6-1800mA White 6000K 56 1800 12000 100 >70
SG9N100W3-1800mA Warm White
3000K		 9600 >80
SG9N120W6-2000mA White 6000K 60 2000 13000 120 >70
SG9N120W3-2000mA Warm White
3000K		 10500 >80
RG12N3W6-350mA 50x7x1 White 6000K 9.3 350 350 3 >70 ≤4.5W
RG12N3W3-350mA Warm White
3000K		 280 >80
RG12N6W6-700mA White 6000K 9.3 700 720 6 >70 ≤9W
RG12N6W3-700mA Warm White
3000K		 570 >80
SG15N3.5W6-25mA Star(Φ11) White 6000K 135 25 430 3.5 >70 ≤5W
SG15N3.5W3-25mA Warm White
3000K		 340 >80
SG15N6.5W6-350mA White 6000K 18.6 350 780 6.5 >70 ≤9W
SG15N6.5W3-350mA Warm White
3000K		 620 >80
SG15N7W6-50mA White 6000K 150 50 800 7 >70 ≤10W
SG15N7W3-50mA Warm White
3000K		 640 >80
SG16N4.5W6-120mA 13.5x13.5x1 White 6000K 37.5 120 480 4.5 >70 ≤6.75W
SG16N4.5W3-120mA Warm White
3000K		 410 >80
SG16N4.5W6-100mA White 6000K 45 100 480 4.5 >70 ≤6.75W
SG16N4.5W3-100mA Warm White
3000K		 410 >80
SG16N6.5W6-180mA White 6000K 36 180 690 6.5 >70 ≤9.75W
SG16N6.5W3-180mA Warm White
3000K		 590 >80
SG16N8.5W6-240mA White 6000K 35.4 240 900 8.5 >70 ≤12.5W
SG16N8.5W3-240mA Warm White
3000K		 770 >80
SG17N11W6-300mA 19x19x1 White 6000K 36 300 1160 11 >70 ≤16.5W
SG17N11W3-300mA Warm White
3000K		 990 >80
SG17N13W6-360mA White 6000K 36 360 1370 13 >70 ≤19.5W
SG17N13W3-360mA Warm White
3000K		 1170 >80
SG17N17W6-480mA White 6000K 36 480 1790 17 >70 ≤25W
SG17N17W3-480mA Warm White
3000K		 1530 >80
SG17N26W6-720mA White 6000K 36 720 2730 26 >70 ≤39W
SG17N26W3-720mA Warm White
3000K		 2340 >80

SMD LED

Pricelist   How to Order
Order No. Chip Wave
lenght
(nm)		 Electro–optical
characteristics		 2Ø1/2 Half
intensity
angle (°)
Raw
mater.		 Emited
color		 Vf(V) lv@20mA
(mcd)
Typ. Max.
X-Type TOP LEDs (PLCC) 3.5 x 2.8mm
PLCC2XW6 GaInN White
5000-7000K		 --- 2.9 3.5 1860~2790 120°
Order No. Chip Wave
lenght
(nm)		 Electro–optical
characteristics		 2Ø1/2 Half
intensity
angle (°)
Raw
mater.		 Emited
color		 Vf(V) lv@60mA
(mcd)
Typ. Max.
X-Type TOP LEDs (PLCC) 5.5 x 5.0mm
PLCC6XW6 GaInN White
5000-7000K		 --- 2.9 3.5 5270~8370 120°
Order No. Chip Wave
lenght
(nm)		 Electro–optical
characteristics		 2Ø1/2 Half
intensity
angle (°)
Raw
mater.		 Emited
color		 Vf(V) lv@20mA
(mcd)
Typ. Max.
TOP LEDs (PLCC) 3.5 x 2.8mm
PLCC2W6-0.2W GaInN/
GaN		 White
5000-7000K		 --- 3.0 3.6 6200 120°
PLCC2W6-0.1W GaInN White
5000-7000K		 --- 2.8 3.2 2635~3255 120°

RGB LED

Pricelist   How to Order
X-Type PLCC4 3.5 x 2.8mm 4pins
Order No. Chip Wave
lenght
(nm)		 Electro–optical
characteristics		 2Ø1/2 Half
intensity
angle (°)
Raw
mater.		 Emited
color		 Vf(V) lv@20mA
(mcd)
Typ. Max.
PLCC4XRGBCT GaAlInP Super Red 620~630 1.8 2.5 200mcd 120°
GaInN Pure Green 520~530 2.8 3.5 560mcd
GaInN Blue 465~475 2.8 3.5 110mcd
X-Type PLCC6 5.5 x 5.0mm 6pins
PLCC6XRGBCT GaAlInP Super Red 618~628 1.8 2.3 600~900mcd 120°
GaInN Pure Green 520~530 2.9 3.5 1200~1585mcd
GaInN Blue 465~475 2.9 3.5 240~320mcd
PLCC4 2.1 x 2.1mm 4pins
PLCC4RGB-2121 GaAlInP Super Red 620~630 1.8 2.5 115mcd 105°
GaInN Pure Green 520~530 2.8 3.5 290mcd
GaInN Blue 465~475 2.8 3.5 40mcd

OVAL LED 3.9x3.2mm

Pricelist   How to Order
Order No. Chip Wave
lenght
(nm)		 Lens
color		 Electro–optical
characteristics		 2Ø1/2 Half
intensity
angle (°)
Raw
mater.		 Emited
color		 Vf(V) lv@20mA
(mcd)
Typ. Max.
3751XR2D-S AlGaInP Red 620-630 Red
Diffused		 1.7 2.5 830-1440 105°/55°
3751XG2D-S GaInN Green 520-530 Green
Diffused		 3.0 3.6 1700-2880 105°/55°
3751XB7D-S GaInN Blue 465-475 Blue
Diffused		 3.0 3.6 300-620 105°/55°

3W Power LEDs

400mA/9.3V

Star type with no lenses
Angle 120 deg.
Order No. Chip Dom.
wave
lenght
(nm)		 Electro–optical
characteristics		 Spatial
Radiation
Pattern
Raw
mater.		 Emited
color		 Vf (V) Flux
@ 400 mA
Typ. Max.
SR12N3W6C
Datasheet		 GaInN White 5000~6500K --- 9.3 --- 280~400 lm Lambertian
SR12N3W3C
Datasheet		 GaInN Warm White 2500~3500K --- 9.3 --- 200~320 lm Lambertian

4W Power LEDs

400mA/12.8V

Circular type with no lenses
Angle 120 deg.

Order No. Chip Dom.
wave
lenght
(nm)		 Electro–optical
characteristics		 2ø1/2 Half
intensity
angle (deg)
Raw
mater.		 Emited
color		 Vf (V) Flux
@ 400 mA
Typ. Max.
4VAC13CW6
Datasheet		 GaInN White 5000~6500K --- 12.8 --- 400~600 lm 120
4VAC13CW3
Datasheet		 GaInN Warm White 2500~3500K --- 12.8 --- 280~450 lm 120

7W Power LEDs

400mA/19.2V

Square type with no lenses
Angle 120 deg.

Order No. Chip Dom.
wave
lenght
(nm)		 Electro–optical
characteristics		 2ø1/2 Half
intensity
angle (deg)
Raw
mater.		 Emited
color		 Vf (V) Flux
@ 400 mA
Typ. Max.
SS12N7W6C
Datasheet		 GaInN White 5000~6500K --- 19.2 --- 600~900 lm 120
SS12N7W3C
Datasheet		 GaInN Warm White 2500~3500K --- 19.2 --- 450~700 lm 120

8W Power LEDs

400mA/22.5V

Square type with no lenses
Angle 120 deg.

Order No. Chip Dom.
wave
lenght
(nm)		 Electro–optical
characteristics		 2ø1/2 Half
intensity
angle (deg)
Raw
mater.		 Emited
color		 Vf (V) Flux
@ 400 mA
Typ. Max.
SS12N8W6C
Datasheet		 GaInN White 5000~6500K --- 22.5 --- 600~900 lm 120
SS12N8W3C
Datasheet		 GaInN Warm White 2500~3500K --- 22.5 --- 500~800 lm 120

10W Power LEDs

400mA/29V

Circular type with no lenses
Angle 120 deg.

Order No. Chip Dom.
wave
lenght
(nm)		 Electro–optical
characteristics		 Spatial
Radiation
Pattern
Raw
mater.		 Emited
color		 Vf (V) Flux
@ 400 mA
Typ. Max.
10VAC30DW6
Datasheet		 GaInN White 5000~6500K --- 29 --- 800~1400 lm 120
10VAC30DW3
Datasheet		 GaInN Warm White 2500~3500K --- 29 --- 600~900 lm 120
